Hydraulic Forging Presses for Heavy-Duty Metal Forming
XS Hydraulic Forging Presses are used for controlled metal forming and forging operations where high forming force and controlled press movement are required. Different press configurations can be selected according to the required force, working dimensions, forging process and workpiece requirements.
For project-based orders, the press configuration is confirmed from the actual forging process, workpiece dimensions, tooling and production requirements.
Hydraulic Forging Press Range
XS supplies hydraulic forging presses in different configurations according to press force, stroke, working dimensions, tooling and forging requirements.
50 Ton Forging Press
A 50-ton hydraulic press for forging and metal-forming applications.
|
Parameter |
Specification |
|
Press Force |
50 tons |
|
Stroke |
Machine-specific |
|
Working Table |
Machine-specific |
|
Working Height |
Machine-specific |
Project-Specific Presses
For non-standard forging requirements, XS can configure the press according to the workpiece, forging process, tooling and production requirements.
Refer to the individual product page for complete machine specifications.
Upsetting — Increases Cross-Section
Compresses the heated workpiece along its length to increase its cross-sectional size.
Drawing — Reduces Section and Extends Length
Reduces the workpiece section while increasing its length for elongated forgings.
Piercing — Forms Internal Openings
Creates an internal opening in suitable heated workpieces for subsequent forging or machining.
Die Forming — Produces Defined Forging Shapes
Uses forming dies to shape heated metal into the required geometry
Typical Forged Components
Large Shafts
For heavy shafts requiring upsetting, drawing and section reduction.
01
Rings & Ring Blanks
For forming ring blanks and preforms before subsequent processing.
02
Blocks & Billets
For reducing large billets and blocks to required sections.
03
Flanges & Discs
For heavy circular forgings requiring controlled deformation.
04
Cylinders & Heavy Sections
For large cylindrical and heavy-section components used in industrial equipment.
05
Hydraulic forging press configuration is determined by the forging process, workpiece size, required force and tooling.
Press Force
Matches the forming load required for the material and forging operation.
Stroke & Working Height
Provide the required space for the workpiece, dies and forging cycle.
Working Table
Accommodates the required tooling and workpiece dimensions.
Tooling
Die size, arrangement and clearance should match the selected press.
Production Requirements
Production volume, material and forging cycle may affect the final machine configuration.
Applications
Heavy Machinery
Forging shafts, blocks, discs and other heavy machine components requiring controlled metal deformation.
01
Oil & Gas Equipment
For forged flanges, valve-related components and other heavy metal parts where controlled forming is required.
02
Power & Industrial Equipment
For large forged sections, shafts and circular components used in heavy industrial equipment.
03
General Forging Production
Suitable for forging workshops and manufacturers producing different forged shapes from heated metal billets.
04
Manufacturer & Quality Assurance
80+ Years of Manufacturing Experience
Established in 1946, XS has more than 80 years of experience in machine tool manufacturing.
Large Manufacturing Base
XS operates a large manufacturing facility with extensive production and engineering resources for heavy machine tool manufacturing.
Machine Inspection Capability
ZEISS CMM equipment and laser interferometers are available for dimensional and machine inspection.
ISO Management Systems
XS operates under ISO 9001 and ISO 14001 management systems.
Export Experience
XS equipment has been supplied to more than 40 countries and regions.
Packing, Shipment & Installation
Shipment Preparation
Machine components are prepared according to their dimensions, weight and transportation requirements.
Export Packing
Major components are protected and identified for handling during loading, transportation and installation.
Installation Support
Installation and commissioning requirements can be confirmed according to the machine configuration and project scope.
What to Send for a Hydraulic Forging Press Quotation
Forging Drawing or Workpiece Dimensions
Finished forging drawing, overall dimensions, critical sections and approximate weight.
Material & Billet Information
Material grade, billet or ingot dimensions and initial weight.
Forging Process
Required operations, such as upsetting, drawing, piercing or die forming.
Required Press Capacity
Provide the required tonnage if already known. If not, XS can evaluate the required capacity from the forging data.
Working & Tooling Requirements
Provide required stroke, working dimensions, die dimensions and tooling information when available.
Production Requirement
Expected production volume, batch size and operating conditions
Existing Equipment
For replacement projects, provide the current press model, capacity, stroke, working dimensions and tooling information.
Delivery Location
Destination country and city or port for shipment planning.
FAQ
Q: Can I inspect the hydraulic forging press before shipment?
A: Yes. Factory inspection can be arranged according to the agreed inspection requirements. Third-party inspection can also be discussed when required.
Q: Does XS provide technical and operating documentation?
A: The final machine can be supplied with the technical and operating documents applicable to the approved configuration. Documentation requirements should be confirmed before production.
Q: What site preparation is required for installation?
A: Site requirements may include a suitable foundation, installation space, power supply and lifting access. Final requirements depend on the selected machine configuration.
Q: Does XS provide installation and commissioning support?
A: Installation and commissioning support can be arranged according to the machine configuration and project scope.
Q: Are spare parts available after the warranty period?
A: Replacement and maintenance parts can be supplied according to the machine model and component requirements.
Q: What warranty is provided with the press?
A: Warranty terms depend on the final machine configuration and sales contract. The applicable coverage is specified in the quotation and purchase agreement.
Q: Can the machine be supplied for export projects?
A: Yes. XS has supplied equipment to more than 40 countries and regions. Shipping, export documentation and delivery terms can be confirmed according to the destination.
